Lord Fin Tube--Alloy Tube as per ASME SB 163 Monel400 Qty 37 PCs

High Alloy Tube as per ASME SB 163 Monel 400

Tubes SB-163  400 (MONEL)

Size De: 25.4  th=2.77     LG=9172

quantity= 37 PCs




Monel 400 Chemical composition

Alloy
%
Ni
Cu
Fe
C
Mn
Si
S
Monel400
Min.
63
28





Max.

34
2.5
0.3
2
0.5
0.024
Monel 400 Alloy minimum mechanical properties in the room temperature
Alloy state
Tensile strength
Rm N/mm²
Yield strength
R P0. 2 N/mm²
Elongation
A 5 %
Monel400
480
170
35


UNS

Trademark

W.Nr

N04400

Monel400

2.4360


Monel 400 tube alloy is a multi-purpose material in many industrial applications:

1. Seamless water tube in the power factory

2. Sea-water exchanger and evaporator

3. Sulfuric acid and hydrochloric acid environment

4. Crude distillation

5. Sea-water in the use of equipment and propeller shaft

6. Nuclear industry and used in the manufacture of uranium enrichment isotope separation equipment

7. Manufacturing hydrochloric acid equipment used in the production of pump and valve


Keywords: Fin tubes, Finned tube, Finned Pipe Helical Finned Tubes, Solid fin tubes, Serrated finned tube, Helical Serrated Finned Tubes, Tubos Aletados


ASTM A249/A249M Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser tubes

ASTM A268/A268M Standard specification for Seamless and Welded Ferritic and Martensitic Stainless Steel Tubing for General Service

ASTM A269/A269M, ASME SA269/SA269M Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service

ASTM A 270 Specification for Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing

ASTM A312/A312M, ASME SA312/SA312M Specification for Seamless and Welded Austenitic Stainless Steel Pipes

ASTM A 358/A 358M Specification for Electric-Fusion-Welded Austenitic Chromium-Nickel Alloy Steel Pipe for High-Temperature Service

ASTM A409/SA409 Welded Large Diameter Austenitic Steel Pipe for Corrosive or High Temperature Service

ASTM B515/ASME SB515

ASTM B516, ASME SB516,

ASTM A554 Specification for Welded Stainless Steel Mechanical Tubing

ASTM A632 Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing (Small-Diameter) for General Service

ASTM A688/SA688 Standard specification For Welded Austenitic Stainless Steel feedwater heater ‘U’ Tubes

ASTM A731/A731M Seamless and Welded Ferritic and Martensitic Stainless Steel Pipe

ASTM A 778 Specification for Welded, Unannealed Austenitic Stainless Steel Tubular Products

ASTM A789/A789M, ASME SA789/SA789M Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service

ASTM A790/A790M, ASME SA790/SA790M Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe


ASTM A 450/A 450M Specificaion for General Requirements for Carbon, Ferritic Alloy, and Austenitic Alloy Steel Tubes

ASTM A530/A530M Standard Specification for General Requirements for Specialized Carbon and Alloy Steel Pipe

ASTM A 999/A 999M Specification for General Requirements for alloy and Stainles Steel Pipe

ASTM A813/A813M Standard Specification for Single- or Double-Welded Austenitic Stainless Steel Pipe

ASTM A814/A814M Standard Specification for Cold-Worked Welded Austenitic Stainless Steel Pipe

ASTM A999/A999M Standard Specification for General Requirements for Alloy and Stainless Steel Pipe

ASTM A1016/A1016M Standard Specification for General Requirements for Ferritic Alloy Steel, Austenitic Alloy Steel, and Stainless Steel Tubes


German-Standards

DIN 2463-1Welded austenitic stainless steel tubes: dimensions and masses per unit length

DIN 17455 Welded circular stainless steel tubes with general quality requirements -Technical delivery conditions

DIN 17457 Welded circular austenitic stainless steel tubes subject to special requirements


EN Standards

EN 10216-5 Welded Stainless Steel Tube

EN 10217-7 Welded steel tubes for pressure purposes - Technical delivery conditions - Part 7: Stainless steel tubes

EN 10296-2 Welded circular steel tubes for mechanical and general engineering purposes - Technical delivery conditions - Part 2: Stainless steel


Australian Standards

AS 1528 Tubes (Stainless Steel) and Tube Fittings for the Food Industry.


JIS-Standards

JIS G 3447 Stainless Steel Sanitary Pipes

G 3448 Light Gauge Stainless Steel Tubes for Ordinary Piping

G 3459 Stainless Steel Pipes

G 3468 Large Diameter Welded Stainless Steel Pipes

G 3463 Stainless Steel Boiler and Heat Exchanger Tubes

G 3446 Stainless Steel Pipes for Machine and Structural Purposes
